Sandstone from rivers, formed by grains of quartz kept together by siliceous cement. It is classified as a sublitharenite.
The main characteristic of Pinta sandstone is the contrast in colour. Tones range from white with orange veining to cream with red veining.
The quarries, located in the municipality of Regumiel de la Sierra, have 6 metre-high faces that guarantee a high volume of reserves.
|
|
 |
 |
Bulk density
(UNE-EN 1936:1999)
2140 kg/m3 |
 |
Resistance to anchorages
(UNE-EN 13364:2002)
550 N |
|
 |
True porosity
(UNE-EN 1936:1999)
19,2% |
 |
Abrasion resistance
(UNE-EN 1341:2002)
31,5 mm |
|
 |
Friction resistance
(UNE-EN 14231:2004)
76 USRV |
 |
Flexural strength
(UNE-EN 12372:1999)
2,6 MPa |
|
 |
Linear coefficient of thermal expansion
(UNE-EN 14581:2006)
9,96·10-6·C-1 |
 |
Freeze/thaw resistance (12 cycles)
(UNE-EN 12371:2002)
2,5 MPa
|
|
 |
Capillary suction
(UNE-EN 1925:2006)
153,0•g/(m2*t0,5)
|
 |
Compressive strength
(UNE-EN 1926:2007)
31 MPa
|
|
|
Freeze/thaw resistance (48 cycles)
(UNE-EN 12371:2002)
1,2 MPa
|
 |
Water absorption at atmospheric pressure
(UNE-EN 13755:2002)
6,5%
|
|
 |
Ageing resistance due to thermal shock
(UNE-EN 14066:2003)
0,09% (PESO)
5,5% (Ed)
|
|
|
|
|
 |
|
|
 |
| TILES |
| Sizes: |
60x40; 60x30; 80x40; 100x50
(from thickness = 3 cm.) |
| Thicknesses: |
2, 3, 4, 5, 6, 7, 8, 9 y 10 cm. |
| Finishes: |
Saw cut.
Bush hammered (from thickness = 4 cm.).
hand stripped (from thickness = 4 cm.).
Pitched face . |
| ASHLARS |
| Thicknesses: |
from thickness 10 cm. |
| Finishes: |
Bush hammered.
hand stripped. |
| SLABS |
| Thicknesses: |
3, 4, 5, 6, 7, 8 cm. |
| Finishes: |
Saw cut.
Bush hammered. |
| SLABS |
| Thicknesses: |
From 10 cm to 100 cm. |
| Finishes: |
Saw cut. |
| MASONRY |
| Mixed: |
e= 8 / 12 cm. |
| Split: |
e= 18 / 22 cm. |
|
|
 |
 |
 |
 |
| Bush hammered |
Hand stripped |
Pitch-faced |
|
|
|
 |
|
|
