Gris Pinar sandstone is grey, and petrographically it is a medium grain sandstone which has quartz and feldspars as its main components.
The material is obtained from a quarry in Barcelona, from where it is shipped to the cutting workshop for its treatment.
The layout of the strata in large banks allows large blocks of high tonnage to be obtained. These blocks are then prepared into different sizes and surface finishes.
|
|
 |
 |
Bulk density
(UNE-EN 1936:1999)
2373 kg/m3 |
 |
Resistance to anchorages
(UNE-EN 13364:2002)
850 N |
|
 |
True porosity
(UNE-EN 1936:1999)
10,5% |
 |
Abrasion resistance
(UNE-EN 1341:2002)
21,5 mm |
|
 |
Friction resistance
(UNE-EN 14231:2004)
80 USRV |
 |
Flexural strength
(UNE-EN 12372:1999)
5,6 MPa |
|
 |
Linear coefficient of thermal expansion
(UNE-EN 14581:2006)
9,96·10-6·C-1 |
 |
Freeze/thaw resistance (12 cycles)
(UNE-EN 12371:2002)
5,8 MPa
|
|
 |
Capillary suction
(UNE-EN 1925:2006)
28,3•g/(m2*t0,5)
|
 |
Compressive strength
(UNE-EN 1926:2007)
68 MPa
|
|
|
Freeze/thaw resistance (48 cycles)
(UNE-EN 12371:2002)
5,1 MPa
|
 |
Water absorption at atmospheric pressure
(UNE-EN 13755:2002)
4,2%
|
|
 |
Ageing resistance due to thermal shock
(UNE-EN 14066:2003)
0,05% (Weight)
4% (Ed)
|
|
|
|
|
 |
|
|
 |
| TILES |
| Sizes: |
60x40; 60x30; 80x40.
100x50 VARYING SIZES |
| Thicknesses: |
2, 3, 4, 5, 6, 7, 8, 9 and 10 cm. |
| Finishes: |
Sawn cut.
Bush hammered (from thickness = 3 cm.).
Hand stripped (from thickness = 3 cm.).
Pitched face .
Honed. |
| ASHLARS |
| Thicknesses: |
from thickness 10 cm. |
| Finishes: |
Sawn cut.
Bush hammered.
Hand stripped. |
| SLABS |
| Thicknesses: |
2,3, 4 and 5 cm. |
| Finishes: |
Sawn cut.
Bush hammered (from thickness = 3 cm.).
Honed. |
| SLABS |
| Thicknesses: |
From 10 cm to 100 cm. |
| Finishes: |
Sawn cut. |
| MASONRY |
| Mixed: |
e= 8 / 12 cm. |
| Split: |
e= 18 / 22 cm. |
|
|
 |
 |
 |
 |
| Bush hammered |
Hand Stripped |
Honed |
 |
|
|
| Pitch-faced |
|
|
|
|
|
 |
|
|
