Red-cream sandstone with brown-wooden veining with varying intensity as a function of the iron content in the rock.
Its grain is medium-thick and its composition is mainly quartzitic with minimum amounts of micas (muscovite and biotite) and opaque minerals.
This rock is easily cut and is very beautiful. A series of sediment levels from the early cretaceous period from the Pinares region (Burgos) can be found.
In the company workshop, the blocks are cut into different sizes with a wide range of surface finishes such as sawn cut, bushhammered, pitch-faced, etc. .
|
|
 |
 |
Bulk density
(UNE-EN 1936:1999)
2140 kg/m3 |
 |
Resistance to anchorages
(UNE-EN 13364:2002)
550 N |
|
 |
True porosity
(UNE-EN 1936:1999)
19,2% |
 |
Abrasion resistance
(UNE-EN 1341:2002)
31,5 mm |
|
 |
Friction resistance
(UNE-EN 14231:2004)
76 USRV |
 |
Flexural strength
(UNE-EN 12372:1999)
2,6 MPa |
|
 |
Linear coefficient of thermal expansion
(UNE-EN 14581:2006)
9,96·10-6·C-1 |
 |
Freeze/thaw resistance (12 cycles)
(UNE-EN 12371:2002)
2,5 MPa
|
|
 |
Capillary suction
(UNE-EN 1925:2006)
82,2•g/(m2*t0,5)
|
 |
Compressive strength
(UNE-EN 1926:2007)
31 MPa
|
|
|
Freeze/thaw resistance (48 cycles)
(UNE-EN 12371:2002)
1,2 MPa
|
 |
Water absorption at atmospheric pressure
(UNE-EN 13755:2002)
6,57%
|
|
 |
Ageing resistance due to thermal shock
(UNE-EN 14066:2003)
0,09% (Weight ) 5,5% (Ed)
|
|
|
|
|
 |
|
|
 |
| TILES |
| Sizes: |
60x40; 60x30; 80x40 (from thickness = 3 cm.).
100x50 (from thickness = 3 cm.) VARYING SIZES |
| Thicknesses: |
2, 3, 4, 5, 6, 7, 8, 9 and 10 cm. |
| Finishes: |
Saw cut.
Bush hammered (from thickness = 4 cm.).
Hand stripped (from thickness = 4 cm.).
Pitched face . |
| ASHLARS |
| Thicknesses: |
from thickness 10 cm. |
| Finishes: |
Sawn cut.
Bush hammered.
Hand stripped. |
| SLABS |
| Thicknesses: |
3, 4, 5, 6, 7, 8 cm. |
| Finishes: |
Sawn cut.
Bush hammered (from thickness = 4 cm.). |
| SLABS |
| Thicknesses: |
From 10 cm to 100 cm. |
| Finishes: |
Sawn cut. |
| MASONRY |
| Mixed: |
e= 8 / 12 cm. |
| Split: |
e= 18 / 22 cm. |
|
|
 |
 |
 |
 |
| Bush hammered |
Hand stripped |
Pitch-faced |
|
|
|
 |
|
|
